Beginning AutoCAD(R) 2022 Exercise Workbook: For Windows(R)

Just as the AutoCAD software continues to be improved and perfected, so does the Beginning AutoCAD(R) Exercise Workbook. This work is truly the ideal package from which to learn AutoCAD, whether you're a complete beginner, or simply learning about the latest features.
The new AutoCAD 2022 software includes features such as Installer, which reduces the number of steps needed for the initial install, Share Current Drawing, allowing other users to view or edit a drawing in the online AutoCAD Web application, and Trace, encouraging collaboration on drawing changes using the AutoCAD Web and Mobile apps. Readers can download the provided templates used for drawings in the book from the Industrial Press website.
Expert author duo Shrock and Heather share their knowledge with students and instructors, including plenty of inside tips and dozens of exercises to help users get comfortable and see real progress.

New and/or Improved Features in Beginning AutoCAD 2022:

• Redesigned Start Tab--There are three main sections that provide access to recent work, enabling users to carry on where they left off, and offering them access to online saved drawing files. (Included in Lesson 1)
• Count--The new Count feature allows users to count the instances of objects and Blocks that are placed in their drawing. (Included in Lesson 29)
• Floating Drawing Tabs--Users can now drag a drawing file Tab from the main AutoCAD application window to make it a separate drawing file window. This is extremely useful for those with two or more monitors. (Included in Lesson 2)

"I am fascinated by the book Beginning AutoCAD 2022, by Cheryl Schrock and Steve Heather. It is the best book I have found for learning the prerequisites of successfully working with AutoCAD. The authors have done a superb job of leading you all the way from the basics to mastering less known aspects of this program. The lessons are beautifully laid out, and the illustrations are clear, making it simple to master the subject." -- Carl Adkins, Avid AutoCAD UserCheryl Shrock is a retired Professor and Chairperson of Computer Aided Design at Orange Coast College in California. The AutoCAD ExerciseWorkbooks are the result of both her teaching skills and her industry experience. She is an Autodesk(R) registered author.
Steve Heather has more than 30 years of experience as a practicing mechanical engineer, and has taught AutoCAD to engineering and architectural students at the college level. He is a Beta Tester for Autodesk(R), testing the latest AutoCAD software, and a member of the AutoCAD(R) Customer Council.* Starting AutoCAD * AutoCAD Application Window * Creating & Using a Template * Selecting a Command * Drawing Lines * Erase * Undo and Redo * Starting a New Drawing * Opening Multiple Files * Using Floating Drawing Tabs * Automatic Save * Back Up Files and Recover * Circle * Rectangle * Grid and Increment Snap * Layers * Transparency * Object Snap * Zoom * Drawing Setup * Polygon * Ellipse * Point * Break * Trim * Extend * Move * Drag * Nudge * Explode * Copy * Mirror * Fillet * Chamfer * Single & Multiline Text * Tabs & Indents * Spell Check * Columns * Paragraph & Line Spacing * Editing * Coordinate Input * Direct Distance Entry (DDE) * Measure Tools * Moving the Origin * Displaying the UCS Icon * Polar Coordinate Input * Dynamic Input * Using Polar Tracking & DDE * Polar Snap * Offset * Properties Palette * Quick Properties Panel * Array * Scale: Stretch: Rotate * Hatch Types * Editing Hatch Set Properties * Linear, Continue, & Baseline Dimensioning * Editing Dimension Text Values * Modifying a Dimension Style * Dimension Breaks * Adjusting the Distance Between Dimensions * Dimensioning Diameters & Radii * Angular Dimensioning

Author: Cheryl Shrock, Steve Heather
Binding Type: Paperback
Publisher: Industrial Press
Published: 06/21/2021
Pages: 544
Weight: 2.68lbs
Size: 10.94h x 8.43w x 1.10d
ISBN: 9780831136666
